Ideco E-1200 Drilling Rig for Sale
2003 Built Ideco E-1200 Drilling Rig - For Sale
Ideco E-1200 Drilling Rig - 2003 Built for Sale
Used Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Used Drilling Rig for Sale
1200-HP Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Drilling Rig for Sale in USA
Description :
Drawworks Manufacturer :IDECO Model :E-1200 Power :1200-HP Motors :(2) Toshiba 900-HP DC Traction Motors Serial Number :N/A (Asset DW011) Hours :13369
Engines Manufacturer :Caterpillar Model :3512DITA Diesel Engines (x3) Power :1321-HP each Features :Air Start, Skid Mount Enclosures with Generators
Generator Sets Manufacturer :KATO, WEG Model :1050-680361111 Capacity :1050-KW each (x3) Features :Unitized with Engines, Includes VFD/SCR Skid
SCR House Configuration :3x4
Mast Manufacturer :IRI Type :127ft Telescoping Mast Serial Number :D5501271282 Capacity :550,000-LB Hook Load Features :Accommodates 275-Ton Top Drive, Hydraulic Lift Cylinders, Geronimo Line, Mast Dolly
Substructure Manufacturer: IRI Type :22ft Hydraulically Telescoping Substructure Capacity :550,000-LB Rotary Load, 300,000-LB Simultaneous Setback Features :Integrated Drainage System for Fluid Containment, (2) Braden Floor Winches
Rotary Manufacturer :IDECO Model :27-1/2’’ Rotary Drive :Independently driven by (1) 800-HP DC Traction Motor
Blowout Preventer (BOP) Configuration : (1) 11’’ 10M Shaffer Type Double Ram BOP (1) 11’’ 10M Shaffer Type Single Ram BOP (1) 11’’ 5M Shaffer Type Annular (1) KPM Koomey 6 Station Accumulator, Model T15160-3, S/N 2430, API 16E
Mud Pumps Manufacturer :BOMCO Model :F-1600 Triplex Mud Pumps Pressure Rating :5000 PSI Motors :EMD DC Traction Motors rated at 1600-HP
Mud System Total Active Capacity :848 Barrels Components : (2) Covered 424-Barrel Tanks with Round Bottoms and Electric Agitators, each containing (2) 5x6x75-HP Centrifugal Pumps, Remote Hopper Skid (1) Mud Processing Skid, Hydraulically Raised, with (3) Brandt King Cobra Shakers, Brandt DG-10 Degasser, Brandt 16 Cone Desilter (1) Trip Tank Skid, 106-Barrel Capacity, with 2x3x25-HP Centrifugal Pump Suction Tank, 424-Barrel Capacity, (2) 6x5x14 Centrifugal Pumps, includes 100-Barrel Slug Tank Intermediate Tank, 424-Barrel Total Capacity, 3 Separate Tanks at 141-Barrels each, (2)6x5x14 Centrifugal Pumps
Top Drive Manufacturer :Canrig Capacity :275-Ton AC Serial Number :790 Features :"ROCKIT" Capability Hours :21033
Overhead String Configuration :300-Ton Five Sheave Block with a 10 Line String Up
Driller Controls Type :Drillers Cabin Skid Features :Varco Electronic Driller and Block Control System, Block Speed Controls, Joystick Controlled Drawworks Speed, Touch Screen and Manual Control of EDRILL and SCR
Auxiliary Equipment Automatic Catwalk :Forum, Wrangler 3500, S/N 355P0108187AC89, 22.5ft Floor Wireline Unit :Five Star Rig with 25,000ft of .092 Wireline Motorized Drill Line Spool Quarters :Toolpusher and Crew Quarters, Skidded, Furnished, Satellite System Meeting and Change House Combo Skid
Hydraulic Power Unit Skid with Centrifugal Pumps and Reservoir Pipe and Kelly Spinner :Hydraulic (Hawk, Spinmaster, Model 550) Fuel Tank :12,000-Gallons, Double Wall, Skidded with Pump **Water Tank Skid with Centrifugal Pumps
Location : USA
WorldRigs has Ideco E-1200 Drilling Rig - For Sale
Images
Ideco E-1200 Drilling Rig for Sale
2003 Built Ideco E-1200 Drilling Rig - For Sale
Ideco E-1200 Drilling Rig - 2003 Built for Sale
Used Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Used Drilling Rig for Sale
1200-HP Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Drilling Rig for Sale in USA
Ideco E-1200 Drilling Rig for Sale
2003 Built Ideco E-1200 Drilling Rig - For Sale
Ideco E-1200 Drilling Rig - 2003 Built for Sale
Used Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Used Drilling Rig for Sale
1200-HP Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Drilling Rig for Sale in USA
Description :
Drawworks Manufacturer :IDECO Model :E-1200 Power :1200-HP Motors :(2) Toshiba 900-HP DC Traction Motors Serial Number :N/A (Asset DW011) Hours :13369
Engines Manufacturer :Caterpillar Model :3512DITA Diesel Engines (x3) Power :1321-HP each Features :Air Start, Skid Mount Enclosures with Generators
Generator Sets Manufacturer :KATO, WEG Model :1050-680361111 Capacity :1050-KW each (x3) Features :Unitized with Engines, Includes VFD/SCR Skid
SCR House Configuration :3x4
Mast Manufacturer :IRI Type :127ft Telescoping Mast Serial Number :D5501271282 Capacity :550,000-LB Hook Load Features :Accommodates 275-Ton Top Drive, Hydraulic Lift Cylinders, Geronimo Line, Mast Dolly
Substructure Manufacturer: IRI Type :22ft Hydraulically Telescoping Substructure Capacity :550,000-LB Rotary Load, 300,000-LB Simultaneous Setback Features :Integrated Drainage System for Fluid Containment, (2) Braden Floor Winches
Rotary Manufacturer :IDECO Model :27-1/2’’ Rotary Drive :Independently driven by (1) 800-HP DC Traction Motor
Blowout Preventer (BOP) Configuration : (1) 11’’ 10M Shaffer Type Double Ram BOP (1) 11’’ 10M Shaffer Type Single Ram BOP (1) 11’’ 5M Shaffer Type Annular (1) KPM Koomey 6 Station Accumulator, Model T15160-3, S/N 2430, API 16E
Mud Pumps Manufacturer :BOMCO Model :F-1600 Triplex Mud Pumps Pressure Rating :5000 PSI Motors :EMD DC Traction Motors rated at 1600-HP
Mud System Total Active Capacity :848 Barrels Components : (2) Covered 424-Barrel Tanks with Round Bottoms and Electric Agitators, each containing (2) 5x6x75-HP Centrifugal Pumps, Remote Hopper Skid (1) Mud Processing Skid, Hydraulically Raised, with (3) Brandt King Cobra Shakers, Brandt DG-10 Degasser, Brandt 16 Cone Desilter (1) Trip Tank Skid, 106-Barrel Capacity, with 2x3x25-HP Centrifugal Pump Suction Tank, 424-Barrel Capacity, (2) 6x5x14 Centrifugal Pumps, includes 100-Barrel Slug Tank Intermediate Tank, 424-Barrel Total Capacity, 3 Separate Tanks at 141-Barrels each, (2)6x5x14 Centrifugal Pumps
Top Drive Manufacturer :Canrig Capacity :275-Ton AC Serial Number :790 Features :"ROCKIT" Capability Hours :21033
Overhead String Configuration :300-Ton Five Sheave Block with a 10 Line String Up
Driller Controls Type :Drillers Cabin Skid Features :Varco Electronic Driller and Block Control System, Block Speed Controls, Joystick Controlled Drawworks Speed, Touch Screen and Manual Control of EDRILL and SCR
Auxiliary Equipment Automatic Catwalk :Forum, Wrangler 3500, S/N 355P0108187AC89, 22.5ft Floor Wireline Unit :Five Star Rig with 25,000ft of .092 Wireline Motorized Drill Line Spool Quarters :Toolpusher and Crew Quarters, Skidded, Furnished, Satellite System Meeting and Change House Combo Skid
Hydraulic Power Unit Skid with Centrifugal Pumps and Reservoir Pipe and Kelly Spinner :Hydraulic (Hawk, Spinmaster, Model 550) Fuel Tank :12,000-Gallons, Double Wall, Skidded with Pump **Water Tank Skid with Centrifugal Pumps
Location : USA
WorldRigs has Ideco E-1200 Drilling Rig - For Sale
Images
Ideco E-1200 Drilling Rig for Sale
2003 Built Ideco E-1200 Drilling Rig - For Sale
Ideco E-1200 Drilling Rig - 2003 Built for Sale
Used Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Used Drilling Rig for Sale
1200-HP Ideco E-1200 Drilling Rig for Sale
Ideco E-1200 Drilling Rig for Sale in USA
