F200-DEC (Two Available) Drilling Rigs for Sale
Mechanical Land Drilling Rigs for Sale
1780hp Land Drilling Rigs for Sale in USA
Description
F200-DEC (Two Available) Drilling Rigs
1780 HP Mechanical Land Drilling Rigs
Drawworks :
Upetrom type TF25, Rated input power 1780HP, Drilling line
guide Upetrom, Upetrom Make-up cathead & Break-out cathead,
FH 46 Brake, 175 bbl Brakes cooling system capacity, water
cooled, DAAS Automatic drilling control, Upetrom Crown-O-matic
device, powered by (1) Faur motor and (1) MB820 motor 890 HP each.
Mast :
MA 200 Upetrom mast, 137’, 441,000# SHL, 10 lines, racking capacity
of 10,499’ of 5”
Crown Block : Upetrom 240 ton with 6 sheaves grooved for OD 1-1/4” line
Substructure : Upetrom 26’7” x 32’3”, 715,000# setback, 16’4” drill floor height, ,
Clear height between rotary beams and ground level , 3.8
Travelling Block : Upetrom 5-32-MC 200, 200 Ton block, 5 sheaves
grooved for OD
1-1/4” line
Hook Block : Upetrom 200 Ton
Air Winches : (2) Upetrom TP1200, 2400# rated
Drilling Line : Mechel Campia Turzil, 1-1/4" x 1900'
Deadline Anchor : Martin Decker 131T, 75,000# static capacity
with OD 1-1/4” drill
Rotary Table : Upetrom MRL 275, 27 ½”, 500 Ton, powered by
FAUR MB 820 motor (890 HP)
Master Bushing : Upetrom, two sided, 27 ½”
Kelly Bushing : Sterom hexagonal/square
Swivel : Upetrom CH200, 200 Ton capacity, 5000psi
Kelly Spinner : Upetrom DIBA
Mud Pump No. 1 : Upetrom 2PN700, 700 HP, with AP-210
pulsation dampeners powered by Electroputure Craiova
MCF 550 KW motor, 737 HP
Mud Pump No. 2 : Upetrom 2PN700, 700 HP, with AP-210
pulsation dampeners powered by Electroputure
Craiova MCF 550 KW motor, 737 HP
Mud Pump Suction Lines : (2) 10” suction lines with (2) Upetrom line
Mud Discharge Lines (Each pump have separate line) : (2) 4” flexible line section
vibrating hose, 5000psi
Stand Pipe Manifold : RON 4 x 5000 connection ends, Cameron valves, 4”Dia, 5000 psi
Stand Pipe : (1) 60’ stand pipe, 4”Dia, 5000 psi
Rotary Hose / Circulating Hose : (2) Phoenix Oradea, 60’, 5000 psi
Engine Generator Sets : (2) Caterpillar 3512, 1725HP
AC Generators : Caterpillar CAT 1750, 1750 KVA, 380 V, 50 Hz
DC Generators/Emergency Generator(S) : (1) Caterpillar GEP 150, 150 KVA, 380V, 50Hz
Air Compressor(S) : (2) Timpuri NOI model
Mud Tanks General : (7) tank system, 2100 bbl total capacity, total usable volume of 1890 bbls
Mud tank No. 1 – 300 bbl : Sand/Trip tank, Neptun SA/2NB16-VO5 electrical agitator
powered by 10HP electric motor, 403x108x102 33’6” x 9’ x 8’6”
Mud tank No. 2 – 300 bbl : Cleaning tank, (3) Neptune SA/2NB16-VO5 agitators
powered by 10HP electric motor, 26’3” x 9’ x 8’6”
Mud tank No. 3 – 300 bbl : Mud tank, (2) Neptun SA/2NB16-VO5 electrical agitators
powered by 10 HP electric motor, 26’3” x 9’ x 8’6”
Mud tank No. 4 – 300 bbl : Mud Tank, (2) Neptun SA/2NB16-VO5 electrical agitators
powered by 10 HP electric motor, 26’3” x 9’ x 8’6
Mud tank No. 5 – 300 bbl : Mud Tank, (2) Neptun SA/2NB16-VO5 electrical agitators
powered by 10 HP electric motor, 26’3” x 9’ x 8’6
Mud tank No. 6 – 300 bbl : Reserve Tank, 26’3” x 9’ x 8’6
Mud tank No. 7 – 300 bbl : Reserve Tank, 26’3” x 9’ x 8’6
Hoppers And Agitators : (2) mud hoppers, (9) Neptun Campina mud agitators p/b 10HP electric
Shale Shaker : (2) Swaco ALS shakers incl. ditch magnet
Mud Cleaner : SWACO (12) 4”cone D-silter, (2) 12” cone D-sander, Aversa Bucuresti centrifugal pump
Degasser : Upetrom vacuum, Aversa Bucuresti centrifugal pump p/b 75 HP motor, mud-gas separator
Trip tank : 300 bbl
Annular Preventer : Upetrom 13 3/8” x 5000, 9” x 5000, 5000 psi
Ram Type Preventer : Upetrom 13 58/8”, 9”, 5000 psi, single or double
Accumulator : (1) 1000 gallon, 2000 psi with Upetrom P6U remote control panel
Choke Manifold : 3'' X 5000
Ancillary Equipment : Drill pipe elevators, pipeslips, pipe casing protectors, collar elevators,
collar slips, safety clamps, elevator links, bit breakers, bit gauges, casing slips for rotary table,
casing elevators, casing tongs casing circulating heads, thread protector, fishing tools
Instrumentation : Weight Indicator, mud pump pressure gauges, rotary speed tachometer,
tong torqueindicator, mud pump stroke indicator & totalizers, mud pit volume indicators,
mud flow volume indicator, drill parameter recorder, drilling drift, mud testing equipment,
Miscellaneous : gas maske, air breathing apparatus spare bottles, first aid equipment, sour gas
monitoring system, portable combustible gas detector, fire fighting equipment
Camp Site : Senior sleeper with attached bath, junior sleeper, (2) recreation rooms, Kitchens and
Mess rooms, camp spares, laundry container, dry store container, showers, toilets, water tank,
generator and |
