Worldrigs ID: WR877
Description :

2015 Atlas Copco Pit Viper 235 Drill
Pressure: 350 psi
Flow: 1.450 cfm
Approx 11.000 Working Hours

Location : South America

Worldrigs ID: WR562

Description :

Drawworks:
Superior 1000M New (2006) Single Drum Drawworks, 1,000 Hp
Lebus grooved for 1-1/4” Drilling Line, Air operated Makeup
& Breakout Catheads, Over-Running Clutch, Air
Driller’s Console, Crown-O-Matic, Right Angle drive for rotary table.

Compound:
2-Engine, In-Line Compound, w/ Right Angle Drive RT
Box For rotary & Draw works drive

Brake:
PARMAC Dual V-80 Hydromatic Brake coupled together

Drawwworks Power:
No. 1 – CATERPILLAR C-18 Diesel Engine S/N# WJH01728,
 600 Hp Rated, w/24 Volt Electric Start, Radiator, Gauges,
OILWORKS C-195-100 Torque Converter S/N3444
 Air clutch
Hours# 21,597
 No. 2 – CATERPILLAR C-18 Diesel Engine S/N# WJH01706,
 600 Hp Rated, w/24 Volt Electric Start, Radiator, Gauges,
OILWORKS C-195-100 Torque Converter S/N1616
 Air clutch
Hours# 21,664

Mast:
DRILLMASTER New 2008 SN#07632 20’1 1”W x 136’H Cantilever Mast,
With a Gross Nominal Capacity of 930,000 Lbs. and a
650,000 Lb. Static Hook Load, Max wind 91 Knots,
 with ten (10) lines. Crown Block w/ (5)42” Sheave Cluster &
1-56”Fast line Sheave grooved for 1-1/4” diameter drilling line.
Each Crown Sheave wire rope groove is flame hardened.
Each Crown Sheave is fitted with Timken roller bearings and grease seals.
Derrick complete with Crown Safety Platform, 20 finger Racking Board W/ electric mule,
Bridal Lines, Tong Counter Weights, Survey Line Sheaves,
Tugger Sheaves, Ladder, Derrick Climber, Geronimo line,
4” Standpipe & Manifold and
Derrick Stand.
Last Certification 8/23/2012

Substructure:
DRILLMASTER New (2009) 29’10”W x 20’H x 48’8”L
(4) Box-On-Box Substructure w/ Rotary Beams, V-Door Ramp,
Stairs, (2) Air Receiver Tanks, NATIONAL Deadline Anchor,
Safety Rails, inside Catwalk Trolley, 7’W x 14’L built in Tool
Room (ODS) (3) Stairs, Outside wall Winterized, Jacking door,
12’ X 12’ Setback spreader, internal stairway, Vapor proof lighting,
Skidded with oilfield tail rolls

Pump: (Primary)
HT F-1000 Triplex Mud Pump New 2006,
S/N HT 20060088, 1,000Hp.
w/ LANZOU Pulsation Dampener S/N HT20060070,
MF 5,000 Psi. Pressure Gauge
FIVE STAR 6”x8”x14” Charging Pump S/N5268 p/b TECO 75 Hp. Electric Motor,
 Chinese 3”Shear Relief Value, Master Skidded w/ (2) Engines belt compound

Pump Power:
CATERPILLAR C-18 Diesel Engine S/N WJHO1283,
575 HP w/24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive EATON 18CB500 Air Flex Clutch,
Mounted Pump Master Skid.
Hours # 17,376
CATERPILLAR C-18 Diesel Engine S/N WJH01322,
575 HP w/ 24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive EATON18CB500 Air Flex Clutch,
 Mounted Pump Master Skid
Hours#16,277

Pump (Secondary)
HT F-1 000 Triplex Mud Pump New 2006,
S/N HT 20060070, 1,000 Hp.
w/ LANZHOU Pulsation Dampener S/N HT20060069,
MF 5,000 Psi. Pressure Gauge
Five Star 6” x 8” x14” Charging Pump S/N5268 p/b Worldwide 75 Hp.
Electric motor,
3” Shear Relief Valve, Master Skidded w/ (2) Engine belt compound

Pump Power
CATERPILLAR C-18 Diesel Engine S/N WJH-00457,
575 HP w/ 24 volt Electric Start, Radiator, Gauges,
V-Belt Drive, EATON 18CB500 Air Flex Clutch,
Mounted pump Master Skid.
Hours#13,788
CATERPILLAR C1-8 Diesel Engine S/N WJH-00373,
575 HP w/ 24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive, EATON 18CB500 Air Flex Clutch,
Mounted Pump Master Skid.
Hours#16,643

Rotating Equipment:

Rotary Table
Chinese ZP 27-1/2”, New 2006, complies with API split master bushings,
W/ drive shaft coupling.

Swivel
Ideco 300

Kelly
5-1/4” x 42’ Hex Kelly W/ HDS Kelly Drive Bushing

Kelly Spinner
OWI 1500 Kelly Spinner S/N 00475B w/ (2) Air Motors, New

Kelly Valves
Upper Kelly Valve.
Lower Kelly Valve

Travelling Equipment
Sentry Rig Equipment Company
260 Ton Capacity New 2006
4G260 Traveling Block w/ (5) 36” Sheaves, 1-1/4” Line,
Unitized “Hydra-Hook” 260 Ton Capacity

Blowout Preventer and Valves
1 Each -13-5/8" X 5000# Jiangsu Xianz hong Petroleum
Double Gate BOP, Top & Bottom Stud configuration
Including - 1set of 5" Pipe Rams Blocks & 1set of Blind Rams,
With 2 - 4" outlets on each side of Body of BOP

1 Each - 13-5/8" Jiangsu Xianz hong Petroleum  ANNULAR BOP
Includes rubber element

1 Each - 13 5/8" X 5000# Type D Drilling Spool W/ - 2" Side Outlet & 3" Side Outlet
[Matched To Choke Manifold

1 Each - Choke Manifold - 3" X 5000# Complete
 Inc - Steel Flex Line W/ Flanges To Connect
To BOPS or Drilling Spools

Closing Unit
2008 Jiangsu Xianz hong Petroleum Model FXQ640-6
Closing Unit Accumulator, 6 Station,
 Rig Floor Controls and monitor panel,
Complete W/ 15 Bottles, 30 HP Cat 3517 Charge Pump, 21 Air Pumps, & set up
for Nitrogen Bottle Backup
Suitcase Closing Unit Skid 7’-1 0” x 35’ with junk basket

Choke Manifold and Valves
Jiangsu Xianz hong Petroleum Choke Manifold w/ (1) 5-Way Cross,
(3) 4-1/16”x 5M
Gate Valves, (4) 2-9/16” x 5M Gate Valves, (1) Manual
Adjustable Chokes, Hydraulic Adjustable Chokes, Mounted Oil Field Skid.
W/ 2 Kill Valves- & 2-Choke Valves mounted at drilling spool

Rig Houses:
Dog House, DRILLMASTER 9’ 1 1”W x 39’ 1 1”L
Doghouse / Change house Combination w/ 17’5”L
Driller’s House w/ Knowledge Box (5) Lockers, Bench Storage, Heater, Lights.
 5’L Breezeway, 1 7’5”L Change House, w/Bench Storage, (16-Lockers,
Cabinets, Heater & Lights. Oil Field Skidded

Generator/Utility Houses
DRILLMASTER 1 1’10”W x 37’9”L x 11’ 6” T
Utility House w/Lights, Oil Field Skidded to include the following items.

No #1 380 Kw. AC CATERPILLAR Generator Package Powered by Caterpillar C-15
Diesel Engine S/N JRE01986 w/ 24 Volt Electric Start, Radiator, HD Air cleaner Gauges.
Marathon 572RSL4025 Generator End SN# 550989-0506, complete with Oil Field skid.
Hours# 17,278

No #2 380 Kw. AC CATERPILLAR Generator Package Powered by Caterpillar C-15
Diesel Engine S/N JRE01985 w/ 24 Volt Electric Start, Radiator, HD Air cleaner Gauges.
Marathon 572RSL4025 Generator End SN# 550989-0507, complete with Oil Field skid.
Hours# 16,933

NO. 1 GARDNER-DENVER EBE99N New 2006
Electro Saver II Rotary Screw Air Compressor S/N# S237421,
P/b TOSHIBA 30 Hp. Electric Motor, Mounted 240 Gallon Horizontal Tank.
Hours# 15,128

SIEMENS Interlock Panel, 600 Amp 480 Volt Main Lockout Disconnects breakers.

ALLEN BRADLEY Electrical Load center with magnetic starter & breakers,

SQUARE D 225 amp 240 volt panel with breakers

SQUARE D 75KVA Transformer 480 volt to 240 volt

DRILLMASTER 7’9”W x 13”H x 43’1”L Electrical

Suitcase.

DRILLMASTER 2’5”W x 1 3”H x 36’3”L Electrical Suitcases.

Mud System:
DRILLMASTER 9’6”W x 7’H x 34’5”L, 394 Bbl. Suction Tank
10’L Covered Porch, (3) Compartments,
(3) MAX 2000 Mud Agitators p/b TECO 25 Hp. Electric Motors,
Sloped Bottom, Top Mounted Walkways, Safety Rails, Lights, Oil Field Skidded.
FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5284, p/b BALDOR 75 Hp. Electric Motor.
FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5284, p/b BALDOR 75 Hp. Electric Motor.
With internal jetting system, 3 dump gates,

DRILLMASTER 9’6”W x 7’H x 34’7”L, 394 Bbl. Shaker Tank
10’L Covered Porch, (3) Compartments
MAX 2000 Mud Agitator Agitators p/b TECO 25 Hp. Electric Motors,
Sloped Bottom, Top Mounted Walkways, Safety Rails, Lights, Skidded.
With internal jetting system, 3 dump gates,

FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5269,
p/b BALDOR 75 Hp. Electric Motor.

FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5283,
p/b BALDOR 75 Hp. Electric Motor.

SHALE SHAKER, Fluid Systems Inc., Single Screen,
Linear Motion Shale Shaker S/N2450,

SHALE SHAKER, Fluid Systems Inc., Single Screen,
Linear Motion Shale Shaker S/N3089,

NOI DSN-ZH-10CTX Desander S/N 8714-5732,w/ (2) 10” Cones.

NOI DSL-10GG-4CTX Desilter S/N 8714-5731,w/ (10)4” Cones.

DRILCO “Deep Pit” Degasser p/b TECO 10 Hp. Electric Motor

Bubble Buster: Geothermal Type Bubble Buster

Mud House
DRILLMASTER 9’ 1 1”W x 26’L Mud House w/Mud Hopper, Test Sink,
Ventilation Fan, Electric Heater, Lights, Double Side Door, (2) End Doors, Skidded.
Includes 7’H Tri-Stand on one end the other end sets on suction tank.

Fuel Tank
DRILLMASTER 7’1 1”Wx8’Hx30’L, 13,860 Gallon Fuel Tank
w/ (2) AMT 1/2 Hp. Fuel Transfer Pumps p/b BALDOR 1/2 Hp. Electric Motors,
with Three (3)Compartment, Combo Lubester Oilfield Skidded.

Water Tank
DRILLMASTER 10’10”W x 8’1”H x 35’L, 529 Bbl. Water Tank
w/ 10’L Covered Extension, Pump Room, OilField Skidded
FIVE STAR 3”x4”x1 1” Centrifugal Water Pump
S/N 5420, p/b TECO 20 Hp. Electric Motor.
FIVE STAR 3”x4”x1 1” Centrifugal Water Pump
S/N5267, p/b TECO 20 Hp. Electric Motor.

Instrumentation
Weight Indicator
Mud Gauges.

Ancillary Equipment
DRILLMASTER 5’W x 2’4”H x 60’L, 2-Section Catwalk w/ Steel Deck and stands for string blocks.
Pipe Racks 5 Sets 29” x 30’ 1 set 29” x 12’ 1 set 41” x 30’
FIVE STAR “Retriever” Electric Measuring Device S/N 862, w/ 15,000 Ft. of. 092 Wire line
2 sets drill pipe elevators 5”
2 sets of drill pipe slips 5”
2 sets of drill collar slips 7” & 9”
2 sets tongs with all head for pipe & casing
2 sets of safety clamps
Mud box  with 5” rubbers
108” X 4” elevator bails
Crossover, bottom hole, lifting Subs
Air Hoist Air Wrench, Model HUL40, S/N-REM10370, 9000 lb. Pull Rating
Air Hoist Air Wrench, Model KSUL, S/N-REM13962, 10,500 lb. Pull Rating
4,000 Ft. of 1-1/4” Drill Line, Mounted Spooler Stand
3-1/2” X 5,000 Psi. Rotary Hose
Vibrator Hose 2 Each 3 ½” x 18’
Rat hole
Mouse hole
8 rig matting boards
Small hand tools & wrenches
Fluorescent & Mercury-Vapor Rig Lights & Wiring Explosion proof
Atco Office/ living shack all electric w/ oil field skid

Worldrigs ID: WR806
Model : 1000 Drill Rig
Manufacturer : Failing
Condition : Used

Description :

Failing 1000 Water Well Drill Rig
5-1/2" Rotary Table
(2) Leroi Air Compressors (low pressure)
5 X 6 Duplex Mud Pump (with Gardner Denver and Failing Parts installed)
Pipe Rack
Mounted on a 1969 Diamond Rio Truck - VIN #DRE64HC576224
Detroit 8V71 Diesel Engine - rated 318 HP
20 Drill Pipe (2-7/8" OD X 20 x 2-3/8" IF Threads)
(2) Shorter Length Drill Pipe and a Stabilizer

Location : USA

Worldrigs ID: WR803
Model : 2000 Drill Rig & Package
Manufacturer : Gardner Denver
Year : 1978
Condition : Used

Description :

1978 Gardner Denver 2000 Drill Rig
Mounted on a Truck with 2 axles
Cummins 400 Big Cam Diesel Engine
18" GD rotary table (New Seals)
(2) six line blocks with 120,000 lbs hookload/pullback
Newer cables on kelly and pulling lines
2 cat heads
Hydraulic sand line
With hydro brake set up
Gardner Denver 6x10 mud pump with matco quick change fluid end
New 3" kelly hose high pressure
37 ft square kelly

Set up to drill 1600 ft - 2,200 ft water wells
Price Reduced to Sell Fast in July 2020

Included as Package:
1000 ft of 4-1/2" drill pipe
210 ft of 6" drill collars
misc. tooling
pipe truck and trailer

Location : USA

Worldrigs ID: WR628
Model : T64HB Drill Rig
Manufacturer : Schramm
Year : 1969
Condition : Used

Description :

1969 Schramm T64 Drill Rig
Detroit 8V71 diesel deck engine
425 cfm / 250 psi air compressor
300 ft of 4-½inches x 20ft drill pipe
6inches hammer w/ 6inches bit
8inches hammer w/ 8inches bit
2 new motors on head
Last had it running in mid-January 2019
Mounted on a newer 1995 Ford 9000 Truck
Cummins N14 diesel engine
9-speed transmission
2250 tires (estimated 85% good)

Location : USA

Worldrigs ID: WR210

SOLD

Model : B40
Manufacturer : Mobile
Year : 1971
Condition : Used

Description :

1971 Mobile B40 drill rig
6 cylinder 1985 Ford gas deck engine 300 HP
1 winch (3,000 lbs)
CAT Head
2 side rods racks
Mounted on a 1989 Ford F700 truck
Ford 6 cylinder diesel (220,000 miles)
250 Gallon Water Tank
2 Jacks
Slide Base
21 'ft Mast

Note: Set up for Soil Samples Bores, Washboards, and Auger Drilling

Worldrigs ID: WR604
Model : T450 Drill Rig
Manufacturer : Schramm
Year : N/A
Condition : Used

Description :

Schramm T-450 Drill Rig
Holte Casing Hammer
Diesel Deck Engine
Air Compressor is low pressure
Mounted on a Truck
Diesel Engine
53,784 Miles on gauge

Could be sold as a package:
Drill Pipe 600’ ft of 4-1/2” & 185’ ft of 3-1/2”
Tulsa Rig Iron Mud shaker
Pipe Truck
assorted bit and reamers

Location : USA

Worldrigs ID: WR859
Description :

1978 Portadrill 524-3A Drill Rig
Gardner-Denver 5-1/2" Mud Pump
Leroi 256 S-2 250 PSI Air Compressor
Hydrostatic drawworks and rotary table
Pipe Slide
Injection pump
Hydraulic leveling jacks
Mounted on a 1999 Ford Louisville truck
Powered by Cummins Red Top N14 Diesel Engine - rated 500 HP
Tag axle

Location : USA

Worldrigs ID: WR560

Model : T130 Drill Rig
Manufacturer : Schramm
Model Year : 2003
Condition : Used

Description

2003 Schramm T130 Drill Rig - S/N: J130-0707
Detroit DDC/MTU V12-2000TA DDEC Diesel Deck Engine
Mast: Telescoping construction permits long head travel 50’' ft
Note: Shorter length in transport position
130,000 lbs of Pullback
Free standing design with 28"” table opening
Sullair 1350 cfm / 350 psi Air Compressor (Rebuilt with low hours)
Hydraulic pumps (low hours since rebuilt)
Top Head: Fixed position - two hydraulic motors. 0-143 RPM with 106,600 in-lb of torque
Pipe handling sling
Set up for RD20 style (4-½”" X 30'’ X 2-7/8" IF) Drill Pipe
Carousel
Cat Water Injection Pump
Graco Hammer Lubricator
Mounted on a CCC (Crane Carrier Company) Truck - VIN#: 1CYDGD5843T046189
CAT diesel engine
425/65R22.5 front tires 12R22.5 rear tires
Sub Base: 9'’ wide 40'’ long and 3’' tall & Basic Tooling Included

Location : USA

Worldrigs ID: WR833
Description :

2011 Atlas Copco RD20 Range III Drill Rig
Cummins KTAA19 (2019 Model) Diesel Deck Engine 800 Hours
IR HR2.5 1250 cfm / 350 psi Air Compressor
Mounted on CCC (Crane Carrier Company) Truck
Diesel Engine
Currently Working

Location : Middle East Region

Worldrigs ID: WR786
Model : 10R Drill Rig
Manufacturer : Bucyrus Erie
Year : 1972
Condition : Used

Description :

1972 Bucyrus Erie 10R Drill Rig
Started rebuild
Needs back out riggers
No air, or MP
Runs Drives Wont take much to be Drill Ready
Not many hours on this rig for its age

Location : USA

Worldrigs ID: WR695
Model : 650 S/S Drill Rig
Manufacturer : Chicago Pneumatic
Year : 1978
Condition : Used

Description :

1978 Chicago-Pneumatic Model 650 S/S Drill Rig
Caterpillar 3406 diesel engine - serial number 9HB03011
Near new batteries
750 CFM / 125 PSI CO5 Air Compressor
Dynex main pump & Dynex Head motor
Hydraulic winch
27,500 lb. pullback capability
DTH Hammer oiler
4-hole Funk Box (hydraulic pump drive)
REICHdrill dust collector (can be removed if needed)
Operators cab (can be removed if needed)
6-pod drill pipe carousel
Comes with 3 near-new 25 ft. x 5 in. OD drill pipes
New head adapter
New bit sub (tricone bit not included)
3 Hydraulic jacks
Mounted on a 1978 FCCC (Crane Carrier Company) truck
powered by Caterpillar 3208 diesel engine
13-speed Roadranger transmission
showing only 3934 miles on odometer
We also have used 25 ft. length x 4-1/2 in. OD x 3-1/2 in. API Regular
drill pipe available which can be sold at an extra cost, if needed.

Location : USA

Worldrigs ID: WR546

Model : D40K Drill Rig
Manufacturer : Driltech
Condition : Used

Description :

Driltech D40K Drill Rig
50,000 lbs of pullback
high torque head
No carousels (removed for large diameter Well drilling)
dual winches 6000k single line
18000K single line hydraulic Denison P7 main pump - replaced early p-5
All pumps where rebuilt or replaced in 2015 including main gearbox rebuild
Replaced / upgraded to Mercedes tier 4 (I) 550hp diesel deck motor
900 CFM / 300 PSI air compressor
has a mud line and a true 3" mud swivel added to it so it's "mud ready"
New in 2015 radiator/engine cooler rated at 450hp Additional hydraulic cooler added
Mounted on 2012KW tier 4 435hp Paccar heavy spec truck
dual steering and full locking rears
Heavy duty engine Brake
Rig needs a few new hydraulic hoses and new paint job
Note: this machine is 100% California CARB compliant

Location : USA


Worldrigs ID: WR557

SOLD
Model : T3W Drill Rig
Manufacturer : Ingersoll-Rand
Year : 1989
Condition : Used

Description

1989 Ingersoll Rand T3W Drill Rig - S/N: 2900
IR 825 cfm / 350 psi Air Compressor
Caterpillar 3406 diesel deck engine
3636 hours showing on meter (probably turned over & actual
hours might be 13,636)

Sand line winch
Cat water injection pump
Hammer Lubricator
Hydraulic Leveling Jacks
Mounted on a 1989 Ford L8000 Truck
Diesel Engine
74,321 miles

Location : USA

Worldrigs ID: WR785
Model : 250 Drill Rig
Manufacturer : Drillmax
Year : 2015
Condition : Used

Description :

2015 Drillmax 250 Well Drill Rig
One Owner
28ft Mast Tube with Lift Cylinder,
22ft of TopHead Stroke,
Heavy Duty Dual Motor TopHead,
4,000 FT/LBS Torque,
350 RPm,
Side Slide,
2" Swivel Assembly,
6,000 LB Winch with Hydraulic Jib Swing and Extend,
American 5X5 Mud Piston Pump with Variable Volume Output,
Suction Plumbing Below Deck,
Valve Handles for Mud and Air at Control Panel,
Development Air Compressor Package 100 CFM @ 175 PSI. Set Up to
Run at Same Time as Mud Pump,
2" ARO Diaphragm Pump for Grouting,
2" Plumbing to Mud System Including 2" Hardrock Swivel and Hinge Hoses,
12 Volt Electric Double Fan Cooling System,
Drill Pipe Single Rod Loader,
Drill Pipe Storage Rack for Up to 15 Pieces of Drill Pipe,
Hydraulic 24" Breakout Wrench,
3 Spool Helpers Controls to Operate Winch and Jib at Helper Station,
Table with 13" Opening and Breakout Fork to Fit 2-7/8" Drill Pipe,
Variable Control for Feed Pressure System,
4 - Hydraulic Leveling Jacks,
1 - Tool Try,
1 - 36" Tool Box,
Mud Flaps,
Mud Tub,
Mounted on a Dodge Ram 5500 Truck
4x4,
Cummins Diesel Engine,
6 speed transmission,
52 Gallon Fuel Tank,
Still in Use
Engine hours: Idle - 3,225 - (As of December 30, 2019)
Drive hours 378 - (As of December 30, 2019)
Mileage: 11,325 Miles, (As of December 30, 2019)

Location : USA

Worldrigs ID: WR787
Model : 2800 Drill Rig
Manufacturer : Simco
Condition : Used

Description :

Simco 2800 Auger Drill - Unmounted
Year: 1976 / 1977
Dual Motor Hydraulic Top Rotary Power Head (swings away)
11 ft. 6 in. mast (retracted), approximately 18 ft. mast extended
Cathead
Winch
Wisconsin 4 cylindergas motor
In working order
Currently unmounted but comes with trailer it was previously mounted on
included in deal

Location : USA

Worldrigs ID: WR860
Description :

Schramm TXD90 Drill Rig
Diesel Deck Engine
Mounted on a Truck

Included as a package :
1,519 feet of 3-1/2" Drill Pipe
6" Collars = 2 Joints (1) 25ft Long (1) 12ft Long
All Subs needed to drill
Elevators

Location : USA

Worldrigs ID: WR331

Description :


The RB 15 enables the user to drill with the following methods, with borehole
diameters 4” (108 mm) to 24” (609 mm):


Rotary-drilling with direct circulation
Rotary-drilling with reverse circulation Auger-drilling


Percussion core drilling (ram coring)
Wire-line core drilling
Down-The-Hole hammer drilling (direct / reverse)
Free-fall drilling
Geothermal Drilling with DoubleRotation-Head
Inclined Drilling max.45 degrees


Additional rig components
Addit. to specifications overleaf
Foam pumpe
Line oiler (for DTH)
Free-fall winch
Hose winch
Percussion drilling device
Hydraulically driven Gen-set
Hydraulically driven welding-set
Rod handling arm
Rod box


Base carrier : Crawler base


Crawler width / Track shoe width : 2.450 / 500 mm
Transport dimensions L / W / H Diesel Engine (water-cooled) : 10.000 / 2.540 / 3.200 mm
Exhaust Emission Standard : EPA / Carb Tier 3, EU Stufe 3A
Rated output : 205 kW @ 2.200 U/min (rpm)
Diesel tank capacity : 280 l
Feed device (hydr. cylinder)
Push-down / Pull-back force : 70 / 140 kN
Feed speed : 0 - 0,8 m/s


Power swivel : L130
Gear select, 3 speeds
Torque at 0 - 34   rpm : 11.750 Nm
Torque at 0 - 100 rpm : 4.150 Nm
Torque at 0 - 320 rpm : 1.200 Nm


Chuck & break device : HSB 178.300
Clamping diameter max. / min. : 170 / 51 mm
Max. breaking torque : 41.000 Nm


Outrigger cylinder
Max. stroke : 600 mm


Mast head with hydr. swing-out device
Swing-out displacement : 700 mm
Swing-out force : 8 kN


Clamping device
Max. clearance diameter : 400 mm
Max. casing nominal diameter : DN 255
Max. clamping force : 300 kN

Winches
Main winch
Line pull 1st layer : 95 kN
Wire rope diameter / rope length : 20 / 130 m
Coring winch
Line pull 1st layer : 20 kN
Wire rope diameter / rope length : 8 / 300 m
Auxiliary / percussion winch
Line pull 1st layer : 26 kN
Wire rope diameter / rope length : 10 / 49 m

Pumps
Triplex piston pump
Discharge / Operating pressure : 270 l/min / 40 bar
Duplex piston pump
Discharge / Operating pressure : 450 l/min / 20 bar
Eccentric screw pump
Discharge / Operating pressure : 350 l/min / 24 bar
Centrifugal pump
Discharge capacity / Op.pressure : 1.500 l/min / 8 bar
Suction pump
Discharge capacity / Suction height : 5.300 l/min

Screw type compressor Compressor
Discharge / Operating pressure : 7 m³/min / 15 bar
Rotating casing table : VDT 324  VDT 419

Torque : 13 / 20 kNm  30 / 45 kNm

Worldrigs ID: WR687
Model : B57 Drill Rig
Manufacturer : Mobile
Year : 1988
Condition : Used

Description :

1988 Mobile B57 Drill Rig
306 cylinder gas engine on deck
3L6 Moyno water pump
Auto hammer, recently calibrated (8/16/2018)
Cathead
Mounted on Gemco articulated carrier powered by Detroit Diesel
It just finished a job in July that lasted about 4 weeks with borings
as deep as 100 feet.
They went over the whole thing, installed new carburetor.

Location : USA

Worldrigs ID: WR664
Model : 2800 HS (HT) Drill Rig
Manufacturer : Simco
Year : 1992
Condition : Used

Description :

1992 Simco 2800 HS (HT) Drill Rig
Deutz diesel engine on deck
3L6 Moyno pump
Mounted on rubber carrier, powered by 243 Ford gas engine
This rig has been used as recent as February
May have a small oil leak but is all we know that is wrong with it.

Location : USA

Worldrigs ID: WR373

Model : T650 Drill Rig
Manufacturer : Chicago Pneumatic
Condition : Used

Description :

Chicago Pneumatic T650 Drill Rig
GHH 600 CFM / 250 PSI Air Compressor
CAT D343 Diesel Deck Engine
Mounted on a Kenworth Truck
Diesel Engine

Location : USA

Worldrigs ID: WR865
Description :

UDR 1500 Range III Mobile Drill Rig
Mounted on a 2004 International 5800i Tri-Axle Truck
Engine Hours : 11,804
75 ft - 90,000 lb static hook load capacity
hydraulic raise and lower mast
Rexroth 44,000 lb draw works
Top drive
GD mud pump
CAT C15 14.6L diesel engine
525 Adv horsepower
Engine brake
Eaton Fuller 18 speed manual transmission
352” wheel base
40,000 lb front axle
51,000 lb rears
Rig was almost completely overhauled . Hydraulics , hoses, box  etc.

Location : North America

Worldrigs ID: WR178

Model : 1250 Drill Rig
Manufacturer : Failing
Condition : As-Is

Description :

(1) Failing 1250 Drill Rig (being sold for parts)
No Rotary Table
No Mud Pump
No Transfer Case
No Kelly
No Chains
(Basically If You Need A Tower Or Something)
Mounted on a International Truck
Diesel Engine
(1) International 1500 Galloon Water Truck
10 Wheel
Water tank built to bed -O- to haul from pipe beside tank

Location : USA

Worldrigs ID: WR858
Description :

New & Unused 2012 Atlas Copco RD20 Range III XC Drill Rig
Carrier :
Twin H-beam main frame - reinforced 16 in 406.4 mm
5-axle, custom carrier 415 hp 317 kW diesel engine
8-speed transmission Manual with lo - lo and reverse
Tridem rear axles with lockers 23,000 lb each 10,433 kg each
Tandem front steering axles 22,000 lb each 9,979 kg each

Derrick :
Length 61 ft 11 ½ in 18.88 m
Width 4 48 1/2 in 1.23 m
Depth 41 in 1.04 m
Top of table to spindle 51 ft 6 in 5.7 m
Table to ground (rig sitting on tires) 44 in 1,118 mm
Table to ground (jacks fully extended) 92” 2,337 mm

Rig Dimensions :
Height derrick down 13 ft 10 in 4.22 m
Height derrick up 62 ft 6 in 19.05 m
Width 8 ft 4 in 2.54 m
Shipping weight (less tooling) 88,000 lb 40,000 kg

Tip Out Links :
Forged steel 150 ton 136 tonnes
Length 60 in 1,524 mm
Tip out hydraulic cylinder on each link
Angle 0-80° from vertical
Control drillers console

Table & Master Bushing :
Design folding with twin hydraulic jacks
Max opening 26 in 660 mm
API split master bushing 17 ½ in 445 mm
Capacity 60 ton 54.4 tonnes

Rig Performance :
Hookload 120,000 lb 54.4 tonnes
Pulldown 30,000 lbf 13,636 kg
Fast feed up 106 ft/min 32.3 m/min
Fast feed down 180 ft/min 54.9 m/min
Drill feed 29 ft/min 8.8 m/min
Torque 8,000 lbf-ft 10.8 kNm
Speed 0-120 RPM 0-120 RPM
Spindle 3 in 76.2 mm
Swivel Type Multi chevron packings
Opening 2 ½ in 63.5 mm

Location : USA

Worldrigs ID: WR872
Description :

PortaDrill 524 Drill Rig
5 Leveling Jacks
7-1/2" Retractable Rotary Table
26ft Kelly
3 Line Machine (Sand Line & Kelly)
2" Little Giant Swivel
Racking Board
Note: No Rod Included

Location : USA

Worldrigs ID: WR839
Description :

LTD 360 Cable Drill Rig
Carries enough mainline cable to drill to a depth of 450 feet
Bore diameters of 4" to 10" inches
Lift capability of 8,000 lbs for casing removal
40 gallons of on-board water storage with a 40 PSI pump
150 amp arc welder when steel casing is used
20 gallons of fuel (enough to drill about 75 feet)
Rated - Penetration rates usually range between 2-½-5 feet per hour
depending on the geology/ground formations with drilling conditions
Mounted on a 2 axles trailer

Location : USA

Worldrigs ID: WR691
Model : 1500 drill rig
Manufacturer : Gardner Denver
Condition : Used

Description :

Gardner Denver 1500 drill rig
5x6 mud pump
kelly drive recentlly rebuilt
Mounted on a twin axle carrier
Diesel engine
Note: no air compressor on board

Location : USA

Worldrigs ID: WR802
Model : 2800 HSHT Drill Rig
Manufacturer : Simco
Year : 1989
Condition : Used

Description :

1989 Simco 2800 HSHT Drill Rig
8805 hours
Wisconsin VG4D gas deck engine
4x3 Centrifugal mud pump powered by Deutz F4L921 diesel engine (1853 hours)
Mounted on a GMC K3500 Truck 4x4
454 gas engine with 182,638 miles

Location : USA

Worldrigs ID: WR595
Model : T64HB Drill Rig
Manufacturer : Schramm
Year : N/A
Condition : Used

Description :

Schramm T64HB Drill Rig
Detroit 8V92T Diesel Deck Engine
GHH 750 cfm / 300 psi Air Compressor
Myers 10gpm Water Injection Pump
Pipe Rack
3 Hydraulic Leveling Jacks
Mounted on a 1998 International truck
Cummins M11 diesel engine and jake brakes
New tire all around
Included as a Package or Cost Extra:
Used - 300' ft of Drill Pipe (20' x 4-1/2") and basic tooling
Used – (2) 6" Mission Hammers & 8” Stabilizer

Location : USA

Worldrigs ID: WR540

Model : T64HB Drill Rig
Manufacturer : Schramm
Condition : Used

Description :

Schramm T64HB Drill Rig
425 cfm / 250 psi Air Compressor
Detroit 8V71N Diesel Deck Engine
Pipe Rack
3 hydraulic leveling jacks
Mounted on Ford Truck

Location : USA

Worldrigs ID: WR670
Model : SR30 Drill Rig
Manufacturer : Soilmec
Year : 2017
Condition : Used

Description :

2017 Soilmec SR30 Drill Rig
Hours: 1000 (as of Oct 2018)
Cummins QSB6.7-T4F Diesel Engine

Location : Europe

Worldrigs ID: WR103

1995 Foremost Barber DR12/36 drill rig
Sullair 1150 CFM / 350 PSI Air Compressor

Worldrigs ID: WR833
Description :

2011 Atlas Copco RD20 Range III Drill Rig
Cummins KTAA19 (2019 Model) Diesel Deck Engine 800 Hours
IR HR2.5 1250 cfm / 350 psi Air Compressor
Mounted on CCC (Crane Carrier Company) Truck
Diesel Engine
Currently Working

Location : Middle East Region

Worldrigs ID: WR849
Description :

2004 Simco 2800 PTO Drive Water Well / Geothermal Drill Rig
Centerline monoplex mud pump
Secondary 2×3 Centrifugal Mud Pump (400 gpm max/250 psi) (no compressor)
Drillhead (2,850 ft. lbs. max / 0-300 rpm)
11ft Stroke Mast w/ Telescoping Extension (pulldown/pullback 12,000 lbs. max)
Hydraulic Winches
Main : 4500 lbs. 135 fpm
Auxilary : 2550 190 fpm
Split Rod Table and Breakout Wrench
Top Feed Water Swivel / Plumbing Tree
In / Out Hydraulic Slide Base
Down the Hole Hammer Drilling (with Auxilary Air)
Capabilities may vary depending on conditions
Drillhead RPM - 2,850 ft. lbs. max / 0-300 rpm
Pullback 12,000 lbs Max
Push Down - 12,000 lbs Max
Main Winch - 4500 lbs 135 fpm
Auxiliary Winch - 2550 lbs 190 fpm Comes with: 280 feet of Drill Pipe

Other assorted tooling included
PTO Driven from truck engine
Mounted on a 2004 Ford F550 Super Duty Tuck
Only 12,689 miles on odometer
4-Wheel Drive (4x4)
Ford Power Stroke Turbo diesel engine
Manual transmission
(3) Hydraulic Leveling Jacks

Location : USA

Worldrigs ID: WR848
Description :

1997 IMT AF18 Crawler Drill Rig
12,000 hours (+/-) on the rig
Cummins QSL9 Diesel Engine (Tier III & recently installed - only 4,500 hours+/-)

Location : USA

Worldrigs ID: WR672
Model : R-620 Drill Rig - Crawler
Manufacturer : Soilmec
Year : 2006
Condition : Used

Description :

2006 Soilmec R-620 Crawler Drill Rig
Hours: 6,200
R-620
Hydraulic Drilling Rig
A new model : The R-620 drilling rig on caterpillar 3.30C high power
module has been designed to perform the follwing jobs:
Bored pile, with dry or bentonite system;
Bored pile, with casing installed by oscillator or rotary crowd system;
C.F.A (Continuous flight Auger) piles.

The main features of R-620 are the following:
Machine class: 60 tons
New machine caterpillar type 3.30C module c/w diesel engine and
sound proofed canopy,mounted on 360 degrees slew ring
New electronic engine C9 ATAAC wth more power(355Bhp) and
meeting the most recent emission regulations.
New powerful rotary:201 kNm
Completely self erecting;mast able to withstand the max torque
over the whole length.
Casing installation by rotary crowd system
Advanced instrumentation
Reliability and safety
Stability and easy to handle
High productivity
Easy to transport
cable crowd system(optional)
Mechanical and hydraulic pre - arrangement for casing
oscillator(available on request)


Large diameter bored pile
Max pile diameter	mm	1800
Max cased diameter	mm	1500
Max pile depth	m	66
Max nominal torque	kNm	201
Max drilling speed	rpm	34
Spin off	rpm	144
Main winch nominal line pull	kN	192
Service winch nominal pull	kN	80
Engine¹	type	Caterpillar C9 ATAAC-HEUI
Max power	Kw (bhp)	261(355)
Crowd system by cylinder	kN	210/150
Pull  down stroke	mm	5600
Cable crowd system(13m stroke)	kN	200/200
Operating weight	ton	63



Continuous Flight Auger (CFA)
Max pile diameter	mm	900/1000
Max pile depth	m	22.5
Max nominal extraction force	kN	600
Max nominal torque	kNm	201
Max drilling speed	rpm	34
Operating weight	ton	60-63



Location : USA

Worldrigs ID: WR805

SOLD

Model : T3W Drill Rig
Manufacturer : Ingersoll-Rand
Year : 2004
Condition : Used

Description :

2004 Ingersoll-Rand T3W Drill Rig
Engine Hours: 20,621
50 ft – 45,000lb static hook load capacity
hydraulic raise/lower mast
Atlas Topco top drive
Braden 23,000 lb winch
mud system (5” x 6” or 5.5” x 8” GD mud pump)
hydraulic set up to run two pumps or air compressor
hydraulic hoses are re-conditioned
rig derrick can be shortened if requested

Note: no deck engine or air compressor on board the drill
Mounted on International 5600i Truck
Cummins ISX 14.9L Engine
475 Adv horsepower
engine brake
Eaton Fuller 18 speed manual transmission
330” wheel base
8 X 6 20,000lb front axle
54,000lb rears

Location : North America



Worldrigs ID: WR330

General Specification

Basic Data :
- Max. hook load : 500 kN
- Mast height : 13,35 m
- Casing installation height : 8,00 m
- Power swivel working travel : 7,50 m

Dimensions :
- During transport (L/W/H) : approx. 12,90m / 2,50m / 4,00 m
- During drilling operation (L/W/H)  : approx. 10,50m / 3,50m / 13,35 m

Operating Conditions :
- Ambient temperature range : -20°C - +45°C
(up to 52°C with special hydraulic oil)

Drilling Depth :
- at drilling diameter 990mm : approx. 250 m*
- at drilling diameter 150mm : approx.1.200 m*
* Drilling depth depending on geology, drilling method
and applied drill string components.

Applicable Drilling Methods :
- Direct Mud Circulation (DC), external mud pump required
- Reverse Mud Circulation (RC) by Air Lift, external compressor required
- Dry drilling / Auger drilling
- DTH Hammer Drilling, external compressor required
- Wire-Line Core Drilling

Special Specification

Trailer R1
Type : 3-axle semi-trailer
Dimensions in transport position:
- Lenght (excluding mast) : approx. 10.35m
- Length (with mast) : approx.
- Height : approx. 4.00m
- Width : approx. 2.50m
Type of king pin : 2'' or 3'' ( to be specified)
Height of King pin : approx. 1.35m
Permissible total weight : 45.000 kg
Permissible load of King pin : 18.000 kg
Type of tires : 6 x 385/65 R 22,5 + 1 x spare

Rig frame & Levelling jacks
Description :
Heavy duty steel frame, suitable to mount all rig components,
fixed on the chassis of the carrier

Painting : daffodil yellow (RAL 1007)
Number of levelling jacks : 4
Type of levelling jacks : hydraulically, operated independently
Working stroke :600 mm
Pad size diameter : 500 mm

Deck engine MTU
directly flanged to hydraulic pump distributor gearbox

Manufacturer :  TU (Mercedes)
Type : V8, water cooled
Emission level : EPA/CARB Tier III, EEC 97/68EC 3a
Capacity : approx. 750 HP at 1.900 rpm
Electrical system : generator 24 V, 80A
Fuel tank content : 850l

Hydraulic system (Type 2)
Description :
Hydraulic pump distributor gearbox driven by deck engine.
Closed hydraulic circuits for all main components, driven by axial
piston pumps : Power Swivel, Feed device, draw works
(with additional supply pump), Auxiliary hydraulics
(mud pumps, compressor)

Hydraulic oil tank : 1.000l
Type of Hydraulic oil : HVLP 46
(suitable for normal temperature conditions)

Mast RB50 R1
Description :
Constructed of high tensile steel (rectangular tubes),
hydraulically elevated by two (2) double acting hydraulic
cylinder; including: guide rails for power swivel, suspension for
feed device, crown block with sheaves, ladder
for maintenance work.

Total Height in working position : 13.40 m
Operating space (crane block) : 8.80 m
Working stroke (power swivel) :
7.50 m (suitable for drill pipes up to 6.0m length)
Max. load capacity : 500 kN

Boom for discharge hose
Description :
Mast boom for fastening and securing the discharge
hose for air lift drilling, Attached to the right-hand
side of the mast

Projection : approx. 2,70 m
including : Steel cables for fastening and securing
the discharge hose

Feed Device
Pull down-force capacity : 80 kN
Pull back-force capacity :
350 kN (with main hydraulic cylinder)
500 kN (in conjunction with draw works)

Max. feed speed :
0 - 0,54 m/sec at full load
0 - 1,00 m/sec at max 133 kN

Technical features :
- Load compensation, hydraulically controlled, for
  adjustment of defined Weight On Bit (WOB)
- Controlled WOB, hydraulically controlled,
  constant WOB in dependance of penetration rate
- Vertical compensation, hydraulically controlled,
  allows a defined vertical moving of power swivel
(up/down) per  rotation of spindle (left/right) for gentle
thread make up operation

Power Swivel S150.2
Hydraulical Drive : axial piston pump (variable displacement)
Torque :
- gear 1 : 31.580 Nm at 0 -   45 rpm
- gear 2 : 16.600 Nm at 0 -   85 rpm
- gear 3 :  4.150 Nm at 0 - 340 rpm
Max. Mud operating pressure : 40 bar
Inner diameter (free passage) : 150 mm
Connections for :
- heavy duty rotary hose 4" for direct mud circulation
- direct air for DTH Hammer.
- Inlet for 1" air injection pipe (for air reverse circulation
  drilling)

Hydraulic chuck and break device
Description : For making and breaking of drill pipes
Max. pulling force : 500 kN
Max. breaking torque :  48 kNm
Max. Inner diameter (with open clamps) : 195 mm
Max. Outer diameter of drill pipe : 178 mm
Min. Outer diameter of drill pipe : 51 mm

High pressure Inlet for S150, 80 bar : optional (not included)

Hydraulic Clamping Device
Description:
Working Table with hold-back arms swing-mounted at the
mast basis, suitable for interchangeable jaws of different size.

Free passage (closed) : 520 mm
Free passage (open) : 900 mm
Max. clamping diameter : 473 mm (18.5/8'')
Max.clamping force : 500 kN

Make-up and Break-out Device
Description :
Hydraulic cylinder placed on the main frame on the right side,
operated for use with manual tongs, power transfer via chain
system, tongs can be positioned on both sides of the mast for
breaking and tightening the drill pipes, collars and
casing connections.

Pulling force of cylinder : 60 kN
Pulling length of cylinder : 600 mm

Main Winch
Description :
hydraulically driven, suitable for pulling the power swivel or
for installation of casing pipes, operation in combination with
Utility Crane Block 550 kN (triple sheave), overrun safety mechanism

Max. pull-back : 95 kN in first cable layer
Max. cable speed : 2 m/s
Cable length : 90 m
Cable diameter : 20 mm

Auxiliary Winch
Description :
hydraulically driven, with hydraulically released safety brake

Max. pull-back : 25 kN in first cable layer
Cable length : 50 m
Cable diameter : 10 mm

Wire-Line Coring winch 1.000m
Description : hydraulically driven, with hydraulically released safety brake
Max. pull-back : 25 kN in first cable layer
Cable length : 1.000 m
Cable diameter : 8 mm

Features :
- Mechanical holding brake
- Mechanical depth measuring unit with incremental measuring system,
  digital display on the control panel

Mud Line System (standard)
Description :
consisting of horizontal steel pipe system with valves and
connection to the power swivel (vertical pipe and hose)

Diameter : DN 100  / 4"
Max. mud pressure : 60 bar steel pipe system / 80 bar mud hoses
External connections :
4'' (for additional mud pump)
2'' (for external compressor)

Lighting & Electrical system
Voltages : 24V
Mast lights : 3 x Halogen (70 W)
Well head light : 1 x Halogen (70 W), movable
Controll board light : 2 x Halogen (25 W)


Safety system
Description : for quick shut-down of engine and hydraulic
system in case of danger
No. Of emergency shut-off buttons : 2

Operator's platform
Description :
located at the rear left side of the rig with direct sight to the working area,
tiltable, with weather protection tent

Main Control Board
Description : with lockable cover, all gauges and control levers
are labeled by symbols
Main functions :
with electronic pre-control of hydraulic circuits
- Engine start/shut off and speed control
- Engine emergancy alarm
- Manometer of hydraulic circuits
- Power swivel torque
- Power swivel rotation speed
- Hook load indicator
- Pull-up / Pull-down / Weight on bit
- Mud pressure indicator (optional)
- Indicator for pulling force of break-out device
- Depths indicator for coring winch (optional)
- Operating hours (engine, power swivel,...)

Tool box
Description :
Mounted on the drilling rig for basic tools and equipment.
Sufficient for simple maintenance of drilling rig and ancillary equipment.
An additional Tool box will be mounted on the rig and equipped
with additional necessary tools.

Documentation & Certificates
consisting of :
Operation & Maintenance Manual (1x printed / 1x digital)
Parts books / spare parts list (1x printed / 1x digital)

Language : Russian / English
Certificates :

Worldrigs ID: WR852
Description :

1989 Schramm T-660 Drill Rig
Detroit 8V92 Diesel Deck Engine (less than 4000 hours since
complete rebuild with preheater)
GHH 900 cfm / 350 psi Air Compressor (Rebuilt, less than 500 hours,
with clutch)
Jib-Boom
Bean water injection pump
360 ft of drill pipe (20ft x 4-1/2"), table bushings & basic tooling included
7 Rod Carousel Lazy Susan
Pipe Rack
Hydraulic Leveling Jacks
Mounted on a GMC White Brigadier Truck (60k+ miles on gauge)
Cat 3208 (Rebuilt transmission less than 2000 miles ago)
Very good tires
Note: Replaced upper chains when the motor were rebuilt about 3500 hours ago

Current repairs needed we are aware of:
Truck CAT 3208 engine starts very hard but once it starts then it runs fine and
runs good (Rebuild time approaching soon)
Traverse cylinders leak small amounts of oil
Deck deck engine leaks small amounts of oil
Compressor clutch work manually only

Location : USA

Worldrigs ID: WR562

Description :

Drawworks:
Superior 1000M New (2006) Single Drum Drawworks, 1,000 Hp
Lebus grooved for 1-1/4” Drilling Line, Air operated Makeup
& Breakout Catheads, Over-Running Clutch, Air
Driller’s Console, Crown-O-Matic, Right Angle drive for rotary table.

Compound:
2-Engine, In-Line Compound, w/ Right Angle Drive RT
Box For rotary & Draw works drive

Brake:
PARMAC Dual V-80 Hydromatic Brake coupled together

Drawwworks Power:
No. 1 – CATERPILLAR C-18 Diesel Engine S/N# WJH01728,
 600 Hp Rated, w/24 Volt Electric Start, Radiator, Gauges,
OILWORKS C-195-100 Torque Converter S/N3444
 Air clutch
Hours# 21,597
 No. 2 – CATERPILLAR C-18 Diesel Engine S/N# WJH01706,
 600 Hp Rated, w/24 Volt Electric Start, Radiator, Gauges,
OILWORKS C-195-100 Torque Converter S/N1616
 Air clutch
Hours# 21,664

Mast:
DRILLMASTER New 2008 SN#07632 20’1 1”W x 136’H Cantilever Mast,
With a Gross Nominal Capacity of 930,000 Lbs. and a
650,000 Lb. Static Hook Load, Max wind 91 Knots,
 with ten (10) lines. Crown Block w/ (5)42” Sheave Cluster &
1-56”Fast line Sheave grooved for 1-1/4” diameter drilling line.
Each Crown Sheave wire rope groove is flame hardened.
Each Crown Sheave is fitted with Timken roller bearings and grease seals.
Derrick complete with Crown Safety Platform, 20 finger Racking Board W/ electric mule,
Bridal Lines, Tong Counter Weights, Survey Line Sheaves,
Tugger Sheaves, Ladder, Derrick Climber, Geronimo line,
4” Standpipe & Manifold and
Derrick Stand.
Last Certification 8/23/2012

Substructure:
DRILLMASTER New (2009) 29’10”W x 20’H x 48’8”L
(4) Box-On-Box Substructure w/ Rotary Beams, V-Door Ramp,
Stairs, (2) Air Receiver Tanks, NATIONAL Deadline Anchor,
Safety Rails, inside Catwalk Trolley, 7’W x 14’L built in Tool
Room (ODS) (3) Stairs, Outside wall Winterized, Jacking door,
12’ X 12’ Setback spreader, internal stairway, Vapor proof lighting,
Skidded with oilfield tail rolls

Pump: (Primary)
HT F-1000 Triplex Mud Pump New 2006,
S/N HT 20060088, 1,000Hp.
w/ LANZOU Pulsation Dampener S/N HT20060070,
MF 5,000 Psi. Pressure Gauge
FIVE STAR 6”x8”x14” Charging Pump S/N5268 p/b TECO 75 Hp. Electric Motor,
 Chinese 3”Shear Relief Value, Master Skidded w/ (2) Engines belt compound

Pump Power:
CATERPILLAR C-18 Diesel Engine S/N WJHO1283,
575 HP w/24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive EATON 18CB500 Air Flex Clutch,
Mounted Pump Master Skid.
Hours # 17,376
CATERPILLAR C-18 Diesel Engine S/N WJH01322,
575 HP w/ 24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive EATON18CB500 Air Flex Clutch,
 Mounted Pump Master Skid
Hours#16,277

Pump (Secondary)
HT F-1 000 Triplex Mud Pump New 2006,
S/N HT 20060070, 1,000 Hp.
w/ LANZHOU Pulsation Dampener S/N HT20060069,
MF 5,000 Psi. Pressure Gauge
Five Star 6” x 8” x14” Charging Pump S/N5268 p/b Worldwide 75 Hp.
Electric motor,
3” Shear Relief Valve, Master Skidded w/ (2) Engine belt compound

Pump Power
CATERPILLAR C-18 Diesel Engine S/N WJH-00457,
575 HP w/ 24 volt Electric Start, Radiator, Gauges,
V-Belt Drive, EATON 18CB500 Air Flex Clutch,
Mounted pump Master Skid.
Hours#13,788
CATERPILLAR C1-8 Diesel Engine S/N WJH-00373,
575 HP w/ 24 Volt Electric Start, Radiator, Gauges,
V-Belt Drive, EATON 18CB500 Air Flex Clutch,
Mounted Pump Master Skid.
Hours#16,643

Rotating Equipment:

Rotary Table
Chinese ZP 27-1/2”, New 2006, complies with API split master bushings,
W/ drive shaft coupling.

Swivel
Ideco 300

Kelly
5-1/4” x 42’ Hex Kelly W/ HDS Kelly Drive Bushing

Kelly Spinner
OWI 1500 Kelly Spinner S/N 00475B w/ (2) Air Motors, New

Kelly Valves
Upper Kelly Valve.
Lower Kelly Valve

Travelling Equipment
Sentry Rig Equipment Company
260 Ton Capacity New 2006
4G260 Traveling Block w/ (5) 36” Sheaves, 1-1/4” Line,
Unitized “Hydra-Hook” 260 Ton Capacity

Blowout Preventer and Valves
1 Each -13-5/8" X 5000# Jiangsu Xianz hong Petroleum
Double Gate BOP, Top & Bottom Stud configuration
Including - 1set of 5" Pipe Rams Blocks & 1set of Blind Rams,
With 2 - 4" outlets on each side of Body of BOP

1 Each - 13-5/8" Jiangsu Xianz hong Petroleum  ANNULAR BOP
Includes rubber element

1 Each - 13 5/8" X 5000# Type D Drilling Spool W/ - 2" Side Outlet & 3" Side Outlet
[Matched To Choke Manifold

1 Each - Choke Manifold - 3" X 5000# Complete
 Inc - Steel Flex Line W/ Flanges To Connect
To BOPS or Drilling Spools

Closing Unit
2008 Jiangsu Xianz hong Petroleum Model FXQ640-6
Closing Unit Accumulator, 6 Station,
 Rig Floor Controls and monitor panel,
Complete W/ 15 Bottles, 30 HP Cat 3517 Charge Pump, 21 Air Pumps, & set up
for Nitrogen Bottle Backup
Suitcase Closing Unit Skid 7’-1 0” x 35’ with junk basket

Choke Manifold and Valves
Jiangsu Xianz hong Petroleum Choke Manifold w/ (1) 5-Way Cross,
(3) 4-1/16”x 5M
Gate Valves, (4) 2-9/16” x 5M Gate Valves, (1) Manual
Adjustable Chokes, Hydraulic Adjustable Chokes, Mounted Oil Field Skid.
W/ 2 Kill Valves- & 2-Choke Valves mounted at drilling spool

Rig Houses:
Dog House, DRILLMASTER 9’ 1 1”W x 39’ 1 1”L
Doghouse / Change house Combination w/ 17’5”L
Driller’s House w/ Knowledge Box (5) Lockers, Bench Storage, Heater, Lights.
 5’L Breezeway, 1 7’5”L Change House, w/Bench Storage, (16-Lockers,
Cabinets, Heater & Lights. Oil Field Skidded

Generator/Utility Houses
DRILLMASTER 1 1’10”W x 37’9”L x 11’ 6” T
Utility House w/Lights, Oil Field Skidded to include the following items.

No #1 380 Kw. AC CATERPILLAR Generator Package Powered by Caterpillar C-15
Diesel Engine S/N JRE01986 w/ 24 Volt Electric Start, Radiator, HD Air cleaner Gauges.
Marathon 572RSL4025 Generator End SN# 550989-0506, complete with Oil Field skid.
Hours# 17,278

No #2 380 Kw. AC CATERPILLAR Generator Package Powered by Caterpillar C-15
Diesel Engine S/N JRE01985 w/ 24 Volt Electric Start, Radiator, HD Air cleaner Gauges.
Marathon 572RSL4025 Generator End SN# 550989-0507, complete with Oil Field skid.
Hours# 16,933

NO. 1 GARDNER-DENVER EBE99N New 2006
Electro Saver II Rotary Screw Air Compressor S/N# S237421,
P/b TOSHIBA 30 Hp. Electric Motor, Mounted 240 Gallon Horizontal Tank.
Hours# 15,128

SIEMENS Interlock Panel, 600 Amp 480 Volt Main Lockout Disconnects breakers.

ALLEN BRADLEY Electrical Load center with magnetic starter & breakers,

SQUARE D 225 amp 240 volt panel with breakers

SQUARE D 75KVA Transformer 480 volt to 240 volt

DRILLMASTER 7’9”W x 13”H x 43’1”L Electrical

Suitcase.

DRILLMASTER 2’5”W x 1 3”H x 36’3”L Electrical Suitcases.

Mud System:
DRILLMASTER 9’6”W x 7’H x 34’5”L, 394 Bbl. Suction Tank
10’L Covered Porch, (3) Compartments,
(3) MAX 2000 Mud Agitators p/b TECO 25 Hp. Electric Motors,
Sloped Bottom, Top Mounted Walkways, Safety Rails, Lights, Oil Field Skidded.
FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5284, p/b BALDOR 75 Hp. Electric Motor.
FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5284, p/b BALDOR 75 Hp. Electric Motor.
With internal jetting system, 3 dump gates,

DRILLMASTER 9’6”W x 7’H x 34’7”L, 394 Bbl. Shaker Tank
10’L Covered Porch, (3) Compartments
MAX 2000 Mud Agitator Agitators p/b TECO 25 Hp. Electric Motors,
Sloped Bottom, Top Mounted Walkways, Safety Rails, Lights, Skidded.
With internal jetting system, 3 dump gates,

FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5269,
p/b BALDOR 75 Hp. Electric Motor.

FIVE STAR 6”x8”x14” Centrifugal Mixing Pump S/N 5283,
p/b BALDOR 75 Hp. Electric Motor.

SHALE SHAKER, Fluid Systems Inc., Single Screen,
Linear Motion Shale Shaker S/N2450,

SHALE SHAKER, Fluid Systems Inc., Single Screen,
Linear Motion Shale Shaker S/N3089,

NOI DSN-ZH-10CTX Desander S/N 8714-5732,w/ (2) 10” Cones.

NOI DSL-10GG-4CTX Desilter S/N 8714-5731,w/ (10)4” Cones.

DRILCO “Deep Pit” Degasser p/b TECO 10 Hp. Electric Motor

Bubble Buster: Geothermal Type Bubble Buster

Mud House
DRILLMASTER 9’ 1 1”W x 26’L Mud House w/Mud Hopper, Test Sink,
Ventilation Fan, Electric Heater, Lights, Double Side Door, (2) End Doors, Skidded.
Includes 7’H Tri-Stand on one end the other end sets on suction tank.

Fuel Tank
DRILLMASTER 7’1 1”Wx8’Hx30’L, 13,860 Gallon Fuel Tank
w/ (2) AMT 1/2 Hp. Fuel Transfer Pumps p/b BALDOR 1/2 Hp. Electric Motors,
with Three (3)Compartment, Combo Lubester Oilfield Skidded.

Water Tank
DRILLMASTER 10’10”W x 8’1”H x 35’L, 529 Bbl. Water Tank
w/ 10’L Covered Extension, Pump Room, OilField Skidded
FIVE STAR 3”x4”x1 1” Centrifugal Water Pump
S/N 5420, p/b TECO 20 Hp. Electric Motor.
FIVE STAR 3”x4”x1 1” Centrifugal Water Pump
S/N5267, p/b TECO 20 Hp. Electric Motor.

Instrumentation
Weight Indicator
Mud Gauges.

Ancillary Equipment
DRILLMASTER 5’W x 2’4”H x 60’L, 2-Section Catwalk w/ Steel Deck and stands for string blocks.
Pipe Racks 5 Sets 29” x 30’ 1 set 29” x 12’ 1 set 41” x 30’
FIVE STAR “Retriever” Electric Measuring Device S/N 862, w/ 15,000 Ft. of. 092 Wire line
2 sets drill pipe elevators 5”
2 sets of drill pipe slips 5”
2 sets of drill collar slips 7” & 9”
2 sets tongs with all head for pipe & casing
2 sets of safety clamps
Mud box  with 5” rubbers
108” X 4” elevator bails
Crossover, bottom hole, lifting Subs
Air Hoist Air Wrench, Model HUL40, S/N-REM10370, 9000 lb. Pull Rating
Air Hoist Air Wrench, Model KSUL, S/N-REM13962, 10,500 lb. Pull Rating
4,000 Ft. of 1-1/4” Drill Line, Mounted Spooler Stand
3-1/2” X 5,000 Psi. Rotary Hose
Vibrator Hose 2 Each 3 ½” x 18’
Rat hole
Mouse hole
8 rig matting boards
Small hand tools & wrenches
Fluorescent & Mercury-Vapor Rig Lights & Wiring Explosion proof
Atco Office/ living shack all electric w/ oil field skid

Worldrigs ID: WR551

SOLD
Model : TH60 Drill Rig
Manufacturer : Ingersoll-Rand
Year : 1998
Condition : Used

Description :

1998 Ingersoll-Rand T3W Drill Rig
CAT 3406 Diesel Deck Engine
IR HR2 900 cfm / 350 psi Air Compressor
Hammer Lubricator
Bean water injection pump (4 piston)
7885 hours
18,000 LBS Winch
400' ft of (4-1/2” x 20’ 2-7/8IF) drill pipe & basic tooling included
Pipe Rack
Hydraulic leveling jacks
Mounted on 1998 International 2600 Truck
VIN# 1HTGLATT8XH631062
33,148 miles
Caterpillar C-10 diesel engine - rated 350 HP
Jake brakes
10 Speed Spicer Transmission
Power divider
Tires (90%+ Very Good Condition)

Location : USA

Worldrigs ID: WR874
Description :

Gardener Denver 15W Drill Rig
Rebuilt and Painted
Truck engine has been rebuilt
Mud pump has also been rebuilt
10” Gardner Denver Retractable table
58ft Mast
Racking board
Bailing drum
new 2” little giant swivel
new 26ft Kelly
hydraulic pull down
air clutches
4 hydraulic leveling jacks

Location : USA

Worldrigs ID: WR838
Description :

Foremost DR-40 Crawler Drill Rig
700 hours
Cummins Diesel Engine
24" Tracks
1250 CFM / 350 PSI Air Compressor
Water Injection Pump
Winch for rods
Telescopic boom
Mounted on a Tracks carrier

Location : USA

Worldrigs ID: WR682
Model : CME-75 Drill Rig
Manufacturer : CME Drill
Year : 1988
Condition : Used

Description :

1988 CME-75 Drill Rig
Mounted on a newer 1998 Ford 6X4 FT900 Truck
94,866 miles
3 axles
Ford 300 6 cylinder
Gardner Denver 4.5" x 5" FF FXFM Mud Pump,
2 hydraulic Hoists
wireline & cathead
high torque rotary drive
quick disconnect mast
in-out & sideways slide base
140 lb. auto SPT hammer
3 hydraulic Jacks
hydraulic Auger rack
500 gallon water tank
three locking tool boxes
locking storage under water tank and rig
Re-diamond plated rig body Feb. 2010 (garage keep since)

Location : USA

Worldrigs ID: WR832
Description :

2016 Gefco 30K Drill Rig
5,100+ Hours
Mounted on a Peterbuilt 367 6x4 Truck
Cummins rated 550 HP ISX diesel engine (Tier IV)
Sullair 1000 cfm / 350 psi air compressor
Enclosed steel gear box PTO
4 hydraulic leveling jacks
Rotary tophead
6 rod carosel (removed but included in the sale)
15 rod pipe rack
18 gpm Bean water pump
Power sliding holding wrench and table
60” breakout wrench
Pipe spinner
DTH lubricator
Remote controlled jib boom
Moyno 3L8 pump mounted on deck

Location : USA

Worldrigs ID: WR352

Model: 45C Drill Rig
Manufacturer: CME Drill
Year: 2002
Condition: Used

Description :

2002 CME 45C Drill Rig
With 9278 hours
Auto hammer
Wireline winch
Deutz 3 cylinder diesel engine
Mounted on a 2002 Ford F550 Truck 4x4
148,413 miles

Location : USA

Worldrigs ID: WR600
Model : T450BH Crawler Drill Rig
Manufacturer : Schramm
Year : 2004
Condition : Used

Description :

2004 Schramm T450BH Crawler Drill Rig
CAT 3406C diesel engine (newly rebuilt - couple hundred hours on engine)
Sullair 900 cfm / 350 psi Air Compressor (3000 hours since rebuilt)
Hours: 8000 or a little less.
Dust Collector
5-Rod Carousel
Everything is in good working order.
100 ft of Schramm Drill Rods (25 ft. length x 4-1/2 in.) & QL60 6-1/4" bits

Location : USA

Worldrigs ID: WR789
Model : TLS Drill Rig
Manufacturer : PortaDrill
Year : 1978
Condition : Used

Description :

1978 PortaDrill TLS Drill Rig
Rebuilt - Volvo Diesel Deck Engine - rated 500 HP
500 ft. of 3-1/2" inch Drill Pipe included
Pipe Rack
Top head was rebuilt in summer 2018
New Water Injection Pump installed in summer 2018
Mounted on a Truck
Cummins diesel engine

Location : USA

Worldrigs ID: WR886
Description :

2012 Schramm TXD 200 Drill Rig
serial number J135-0216, trailer VIN#: 1K9AD40C1C3268138.
Detroit DDC/MTU 12V-2000 Diesel Deck Engine

Tilt Top Head Drive:
Heavy duty, single reduction gearbox with 4 two-speed disc valve type
hydraulic motors
Variable rotation speed via HRC control
Torque: 0-90 RPM @ 17,750 ft-lbs (24,066 N-m)
0-180 RPM @ 7,670 ft-lbs (10,399 N-m)
Rotation Speed: 0 - 180 RPM ·

Feed System:
50 ft (15.24 M) head travel
200,000 lbf (890 kN) hoist capacity
100 fpm (30.5 m/min) hoist speed
32,000 lbf (142 kN) pulldown
200 fpm (61 m/min) pulldown speed

Drill Table:
Table Opening : 30" inches (768 mm) diameter with table retracted
Hydraulically retractable slip box

Drill Pipe And Casing:
Range III tubular 30 inch capability

Winch:
Planetary design with spring applied hydraulic release brake
9,600 lbf (42.7 kN) bare drum line pull
150 fpm (46 m/min) bare drum line speed
Hydraulic jib boom swing and extend
Auxiliary winch available
The drills have low wear on the cables, bearing and pivot points as well
as the Control panel
All are in excellent/very good condition during last inspection
LoadSafe pipe handling systems (hands free pipe loading system)
mounted on Trailers

Package available  each of the following:
Generator House with 2 Maraathon Model 431CSL6202-B211 60 HZ Phase 1
120/240V 122 KW 504 AMO or 3 Phase 277/480 155 KW 233 AMP poered by
Perkins 6.6 L 1106 IR 2340 Shop air ,Hyd lift with Honda GX392,4000 Gallon
feul tank and 4 lights on roof.
Weatherford T425 Triplex Mud pump powered by John Deere 6135 diesel engine
(Tier IV) - rated 500 HP, 6.50 Plunger 900 PSI, MCM 4x5x14 Super Charge
Centrifugal pump with soap mixing tanks in back
750 BBL Water tank with hydraulic lift dog house
Crew changing house
Crew House
8000 ft of drill pipe (4" DP New 30ft 6" NC40)
(4) 6-1/2” Drill collars
Every unit is clean & straight and it is a very nice package in excellent/very
good condition after inspections in 2020

Location : USA

Worldrigs ID: WR807
Model : Larson Reverse Rotary Drill Rig - Air Assited
Manufacturer : Generic
Condition : Used

Description :

1982 Larson Air Assisted Reverse Rotary Drill Rig with Substructure
New derrick 120,000 lbs rated
rebult hydraulic system in 2010
Caterpillar 6 cylinder deck engine (spare rebuilt engine in a crate)
double draw works
1" main line, 1" laydown line, 1/2" tail out line

Included as a Package:
Doghouse - Wired, lighted, AC, tool room, Geolograph
40ft 5th wheel, tandem wheel, drill pipe trailer
Substructure 15ft X 12ft 8ft Custom fabricated with guard rails
1,500  ft of 6-5/8" ID IF modified
90ft of 14" drill collars
2010 Atlas Copco 950 cfm / 350 psi SRVS1000 CD6 Air Compressor
1,000 gallon fuel storage tank with transfer pump
King swivel
Pilot Hole bits
Reaming Hole oppener bits
Casing Collars

Optional Equipment that Cost Extra:
Complete testing pump equipment, 6 pumps, 800 ft of 10x3.5x2.437" column
tube she, gear head, discharge head
12 Cylinder Caterpillar test engine

Location : USA

Worldrigs ID: WR844
Description :

1994 Ingersoll-Rand T4W Drill Rig
Rebuilt 2006
Rebuilt Cummins KTA19C Diesel Deck Engine (rated 600 HP at 2100 RPM)
Rebuilt in 2006 a IRH2.5 1070 cfm / 350 psi air compressor
Mounted on a CCC (Crane Carrier)
Cummins L10 diesel engine
50,000 lbs of pullback
Setup for 2-7/8" IF Drill Pipe

The following work was performed when rebuilt:
Rebuild of rig and components
Remanufactured Cummins engine KTA19C 600 HP @ 2100 RPM from Cummins
(upgraded from original 545 HP @ 2100 RPM)
Remanufactured IR compressor HR2.5 1070 CFM @ 350 PSI
Rebuilt funk box Rebuilt or new hydraulic pumps and motor
Rebuilt hydraulic cylinder All new hydraulics and air hose
New and upgraded radiator
New and upgraded air compressor, oil cooler and hydraulic oil cooler
Valve spool rebuilt – new seals and control handles
New feed chains upper and lower – Upgraded
New front leaf springs on carrier
New gauges
New wire harness
Rig and all parts sandblasted and painted grey and red
Rig completely serviced – Ready to drill

Additional tooling :
6” IR QL60 Drive Hammer with Bit
6” IR QL60 Drill Hammer with 4-1/2” x 21.5ft heavy wall lead steel with bit
8” IR QL80 Drill Hammer with 6” x 20ft lead steel with bit
4-1/2” X 25ft 2-7/8 API Drill Rod (11 pieces)
6” Casing Drive Plate
8” Casing Drive Plate
10” Casing Drive Plate
1 - Petol Chain Wrench set up for 4-1/2” Drill Rod and 6” Hammer
1 – Petol Chain Wrench set up for 6” Drill Rod and 8” Hammer
Lincoln Welder with Leads
Oxy/Acetalene Torch Setup

Location : Eastern Region

Worldrigs ID: WR697
Model : Rotadrill T64HB Drill Rig
Manufacturer : Schramm
Year : 1974
Condition : Used

Description :

Schramm Rotadrill T64HB Drill Rig
Rebuilt - Detroit Diesel Deck Engine
No Air Compressor on deck
Tool Carrying Cabinet
Reinforced Mast
Heavy Winch line
3 Outriggers
Hydraulic Pull down & Pull Back
Multiple speed top head motor
Hydraulic Cooler
Autofeed
Mounted on a 1974 International RO Truck
Newer 6 Cylinder Engine
Multi-Speed Transmission

Location : USA

Worldrigs ID: WR872
Description :

PortaDrill 524 Drill Rig
5 Leveling Jacks
7-1/2" Retractable Rotary Table
26ft Kelly
3 Line Machine (Sand Line & Kelly)
2" Little Giant Swivel
Racking Board
Note: No Rod Included

Location : USA

Worldrigs ID: WR845
Description :

2001 Foremost DR-24 Drill Rig
Mounted on 2001 Freightliner Truck
Caterpillar C-15 Diesel Engine (rated 500 HP)
4,100 Hours as of 10/16/20
Atlas Copco 900 cfm / 350 psi Air Compressor
24” Diameter Dual Rotary Power Head
Set up for 2-7/8" IF Drill Rod and 6” Beco Rod
4 piston FMC Bean water injection pump
Oil injection system

Package of Tooling :
Jaws 6, 8, 10, 12, 14, 16, 18, 20, 24 inch
Welding (Cage) Clamp 6, 8, 10, 12, 14, 16, 18, 20, 24 inch
Divertor for 4-1/2 inch Drill Rod with adaptors for 6, 8, 10,
12 inch casings
Divertor for 10-3/4 inch drill rod with adaptors for 12, 14, 16, 18,
20, 24 inch casings
Drive Shoes 6, 8, 10, 12, 14, 16, 18, 20, 24 inch
24 - 4-1/2 inch x 20 ft x 2-7/8 IF thread drill rods
6 - 10-3/4 x 20 ft x 6-5/8 Beco thread drill rods
1 – 10-3/4 x 15ft x 6-5/8 Beco thread drill rod
1 - 10-3/4 x 10ft x 6-5/8 Beco thread drill rod
2 – 10-3/4 x 5ft x 6-5/8 Beco thread drill rods
New Miller Welder
Oxy/Acetalene Torch Setup
1 – Petol wrench setup for 4-1/2" Inch drill rod and 6 inch hammer
1 – Petol wrench setup for 6-inch drill rod and 8 inch hammer
6” IR QL60 Drill Hammer with 4-1/2” x 15ft heavy wall lead steel with bit
8” IR QL80 Drill Hammer with 6” x 15ft lead steel with bit
IR QL120 Drill Hammer with 10-3/4" lead steel and subs and
12” bit 12ft - QL120 Bit
2-7/8" IF x 4-1/2" centralizer drill rod for 10" inch casing
24" Inch over the hammer centralizer for QL120 hammer
Cyclone diverter
5 Inch Concrete Discharges Hoses 15 ft
5 Inch Concrete Discharges Hoses 25 ft

Location : USA
